| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 45 | 5304455651 | Screw (Replaces: 5303001343) |
|
$ 14.41 | |||||
| 46 | 5308009762 | Bolt-roller Mtg, Hex Washer Head, 1/4-28 X 1/2, (2) |
|
- | |||||
| 47 | 5303292394 | Channel-shelf Mtg, Side, Refr, (2) |
|
- | |||||
| 48 | 5303292395 | Channel-shelf Mtg, Center, Refr |
|
$ 157.34 | |||||
| 49 | 215507300 | Screw-ctr Channel,hex Head,8(ab) X 1-1/2 |
|
- | |||||
| 58 | 5308002748 | Screw |
|
- | |||||
| 59 | 5308012258 | Screw |
|
$ 2.25 | |||||
| 60 | 5308010253 | Screw |
|
- | |||||
| 78 | 5303274237 | Screw-bracket, Hex Washer Head, 8-32(ca) X 1/2 |
|
- | |||||
| 81 | 5304455650 | Screw (Replaces: 5308016566) |
|
$ 14.18 | |||||
| 83 | 5308000107 | Bracket-connector |
|
$ 33.23 | |||||
| 100 | 5303288973 | Support-crisper Cvr |
|
$ 24.41 | |||||
| 110 | 215363500 | Support-crisper Rod |
|
- | |||||
| 116 | 215426702 | Rod - Crisper Support |
|
- | |||||
| *89655 | 5308016571 | Plug-button, Liner |
|
$ 4.79 |
