01 - Door, Literature
02 - Control Panel
03 - Oven Cavity
04 - Latch Board
05 - Oven Interior
06 - Base Plate
SELECT A DIAGRAM
New Model Search:
| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | LIT8172187 | Literature (use & Care Guide) |
|
- | |||||
| 1 | LIT8172196 | Literature (cook Guide Label) (english) |
|
- | |||||
| 1 | LIT8172197 | Literature (cook Guide Label) (spanish) |
|
- | |||||
| 1 | LIT8172208 | Literature (cook Guide Label) (tech Sheet) |
|
- | |||||
| 1 | LIT8172217 | Literature (cook Guide Label) (instructions, Installation) |
|
- | |||||
| 1 | LIT8172220 | Literature (cook Guide Label) (template, B/i Kit) |
|
- | |||||
| 2 | 4359934 | Front Screen |
|
$ 11.12 | |||||
| 3 | 8172025 | Door Frame Assembly (biscuit) |
|
- | |||||
| 3 | 8172024 | Door Frame Assembly (white) |
|
- | |||||
| 3 | 4359761 | Door Frame Assembly (black) |
|
- | |||||
| 4 | 4359763 | Choke Cover |
|
- | |||||
| 5 | 4359764 | Tape, Seal |
|
- | |||||
| 6 | 4359765 | Latch |
|
- | |||||
| 7 | 4359707 | Spring, Latch |
|
- | |||||
| 8 | 4359710 | Cap |
|
- | |||||
| 9 | 4359844 | Panel, Door (black) |
|
- | |||||
| 9 | 4359936 | Panel, Door (biscuit) |
|
- | |||||
| 9 | 4359843 | Panel, Door (white (stainless Not Available)) |
|
- | |||||
| 10 | 4359933 | Door Assembly (biscuit) |
|
- | |||||
| 10 | 4359841 | Door Assembly (black) |
|
- | |||||
| 10 | 4359840 | Door Assembly (white) |
|
- | |||||
| 10 | 4359839 | Door Assembly (stainless Steel) |
|
- |
