| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 316028703 | Shield-rear Wall |
|
- | |||||
| 2 | 5303051115 | Ballast |
|
- | |||||
| 3 | 3205350 | Bezel Switch (2) |
|
- | |||||
| 4 | 3131277 | Support, Fluorescent |
|
- | |||||
| 5 | 3051222 | Receptacle-fl Lt |
|
- | |||||
| 6 | 3051223 | Receptacle-fl Lt |
|
- | |||||
| 7 | 3131275 | Bulb-fluor |
|
$ 49.40 | |||||
| 8 | 3131267 | Cap End-lh Trim Canopy |
|
- | |||||
| 9 | 3131268 | Cap End-rh Trim Canopy |
|
- | |||||
| 10 | 5303269513 | Electric Clock |
|
- | |||||
| 11 | 5303291241 | Glass Control Panel |
|
- | |||||
| 12 | 3202625 | Knob-oven Control |
|
- | |||||
| 13 | 316042601 | Plate - Instr. Mtg |
|
- | |||||
| 14 | 3205357 | Switch-oven Light |
|
- | |||||
| 15 | 3205358 | Switch-fluor Light |
|
- | |||||
| 16 | 3203026 | Button Clock (8) |
|
- | |||||
| 17 | 5303210951 | Trim-wrapper |
|
- | |||||
| 18 | 5303210952 | Trim-splasher |
|
- | |||||
| 19 | 5303210954 | Trim-canopy |
|
- | |||||
| 20 | 3131241 | Trim-vent |
|
- | |||||
| 21 | 5303131237 | Support, Backguard |
|
- | |||||
| 22 | 5303210953 | Retainer-trim Glass |
|
- | |||||
| 23 | 3131276 | Spacer-fl Lt Mtg |
|
- |
