| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | Y8007P02060 | Grommet | 10 |
|
$ 5.88 | ||||
| 1 | 74004656 | Top, Main (blk) | 10 |
|
- | ||||
| 2 | 74004053 | Igniter, Top Burner | 10 |
|
Immediately | $ 24.25 | |||
| 2 | 74004410 | Igniter | 10 |
|
$ 26.47 | ||||
| 3 | WPW10253196 | Screw (Replaces: Y707113) | 10 |
|
$ 3.76 | ||||
| 3 | WP3412D024-09 | Burner, Sealed (blk) (Replaces: 74003963) | 10 |
|
Immediately | $ 92.69 | |||
| 3 | WP3412D021-09 | Burner, Sealed (blk) (Replaces: 74004425) | 10 |
|
$ 171.61 | ||||
| 4 | 74001769 | Grate, Burner (blk) | 10 |
|
$ 74.59 | ||||
| 5 | 8008P039-60 | Grommet, Glass | 10 |
|
- | ||||
| 5 | 74001299 | Knob, Infinite (blk) | 10 |
|
$ 9.65 | ||||
| 6 | 74002745 | Gasket, Burner | 10 |
|
- | ||||
| 7 | WP3403F088-00 | Cap, Burner (blk) (Replaces: 71003053) | 10 |
|
$ 68.15 | ||||
| 8 | 5111A261-60 | Wire, Igniter - R | 10 |
|
- | ||||
| 8 | 5125A234-60 | Wires, Loose | 10 |
|
- | ||||
| 8 | 5111A610-60 | Wire, Igniter - R | 10 |
|
- | ||||
| 9 | 74004631 | Manual, Use & Care | 10 |
|
- | ||||
| 9 | 74004654 | Manual, Use & Care (frch) | 10 |
|
- |
