Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	5303201444		Cover-fan		Appelez-nous	-
2	5308011763		Knob - Damper Control (w/ Label)		Appelez-nous	-
3	5303001028		Push-nut		Appelez-nous	-
4	5303001331		Damper, Fan				$ 31.71
5	5308000010		Fan Blade			Immediately	$ 49.03
6	5308002748		Screw		Appelez-nous	-
7	5308000124		Orifice Ring				$ 53.58
8	5300157666		Bushing - Motor Mtg, (2)		Appelez-nous	-
9	5303001226		Bracket-front		Appelez-nous	-
10	5308013665		Cover, Evaporator Coil		Appelez-nous	-
11	5303208309		Plug-factory Test Hole				$ 45.50
12	5308013636		Plug, Decorative		Appelez-nous	-
13	5300158289		Motor, Fan			Immediately	$ 149.94
14	5303205119		Bracket, Rear		Appelez-nous	-
15	5308000107		Bracket-connector				$ 33.23
16	5303001470		Drain Trough		Appelez-nous	-
17	5308000097		Support, Coil Cover (2)		Appelez-nous	-
18	5303001198		Tube, Rubber (2)		Appelez-nous	-
19	5303001286		Ferrule-inner		Appelez-nous	-
20	5303001287		Ferrule-outer		Appelez-nous	-
21	5303207353		Seal Ring, Drain Tube				$ 6.81
22	5303210377		Drain Tube, W/ Seal Ring				$ 109.31
23	5308000056		Spout-drain Tube				$ 11.66
24	5303001301		Push Pin-spout (2)		Appelez-nous	-
25	5308000~~~		Channel Rs & Ls		Appelez-nous	-
27	5303001~~~		Grommet-shelf Mtg Rh (4)		Appelez-nous	-
31	5303212487		Cabinet Base		Appelez-nous	-
40	5303212488		Shim, Bottom Hinge				$ 5.25
41	5303212489		Bracket, Bottom Hinge		Appelez-nous	-
42	5303001320		Screw-hinge Gusset Mtg (6)		Appelez-nous	-
44	5308000007		Washer, Nylon (2)		Appelez-nous	-
45	5308000186		Washer, Nylon			Immediately	$ 6.02
46	5303001369		Bracket- Center Hinge		Appelez-nous	-
47	5308012258		Screw				$ 2.25
48	5308000184		Pin-center Hinge				$ 8.87
49	5303202340		Corner Trim-almond (4)		Appelez-nous	-
49	5303202336		Corner Trim-white (4)		Appelez-nous	-
49	5303202337		Corner Trim-avoc (4)		Appelez-nous	-
49	5303202338		Corner Trim-wheat (4)		Appelez-nous	-
49	5303202339		Corner Trim-coffee (4)		Appelez-nous	-
50	5308012843		Hinge-top				$ 71.47
51	5303001037		Shim, Top Hinge				$ 12.39
52	5308012820		Hinge Cover, White		Appelez-nous	-
52	5303001665		Hinge Cover, Wheat		Appelez-nous	-
52	5303001666		Hinge Cover, Coffee		Appelez-nous	-
52	5308012933		Hinge Cover, Almond		Appelez-nous	-
52	5303001664		Hinge Cover, Avoc		Appelez-nous	-
53	5303001679		Plug, Coffee (2)		Appelez-nous	-
53	5303001678		Plug, Wheat (2)		Appelez-nous	-
53	5303001389		Plug, Almond (2)		Appelez-nous	-
53	5303001677		Plug, Avocado (2)		Appelez-nous	-
53	5303001388		Plug, White (2)				$ 2.60
54	5303212922		Screw-leveling,(2)				$ 10.71
55	5303001546		Cover - Air Deflector		Appelez-nous	-
56	5308000071		Air Deflector		Appelez-nous	-
*40636	5308016571		Plug-liner (6)				$ 4.79
10A	5303209814		Nut U, Type (2) (non-illustrated)		Appelez-nous	-
10B	5304455650		Screw   (Replaces: 5308016566)				$ 14.18
15A	5303210353		Screw-bracket Mtg (non-illustrated)		Appelez-nous	-
1A	G185863		Label-fan Cover-upr (non-illustrated)		Appelez-nous	-
1B	G185864		Label-fan Cover-lwr (non-illustrated)		Appelez-nous	-
1C	5304455650		Screw   (Replaces: 5308016566)				$ 14.18
22A	5304455651		Screw   (Replaces: 5303001343)				$ 14.41
25A	530801~~~~		Screw-channel (6) (non-illustrated)		Appelez-nous	-
27A	5304500407		Grommet-shelf Mtg-lh (4) (non-illustrated)   (Replaces: 5308009759)			Immediately	$ 6.38
41A	5303212597		Tapping Plate/gusset, Rh (non-illustrated)		Appelez-nous	-
41B	5303212596		Tapping Plate/gusset, Lh (non-illustrated)		Appelez-nous	-
50A	241710601		Screw   (Replaces: 5303001479)				$ 13.46
50B	5308012296		Tapping Plate				$ 47.44
