SELECT A DIAGRAM

01 - Body


02 - Control Panel


03 - Control System


04 - Door


05 - Internal Controls


06 - Oven


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	7201P036-60		Gasket, Oven				$ 118.90
2	3804F012-45		Retainer, Lamp Guard		Appelez-nous	-
3	7201P015-60		Gasket, Lamp Retainer		Appelez-nous	-
4	7201P014-60		Gasket, Housing		Appelez-nous	-
4	7902P057-60		Glass, Lamp Guard		Appelez-nous	-
5	7101P287-60		Screw, Metal Grounding				$ 12.03
6	4001F020-19		Housing, Lamp		Appelez-nous	-
7	40A15		Bulb, Oven   (Replaces: 7407P026-60)			Immediately	$ 1.98
8	3807F386-45		Support Baffle		Appelez-nous	-
9	3807F205-45		Support, Oven Rear		Appelez-nous	-
10	12001655		Oven Sensor   (Replaces: 7430P007-60)			Immediately	$ 41.01
11	W10124350		Not Required Part Or See Note		Appelez-nous	-
12	7801P031-60		Rack, Oven		Appelez-nous	-
13	WP74003976		Screw W/washer   (Replaces: 7101P124-60)				$ 6.47
13	7002P009-60		Insulation, Baffle		Appelez-nous	-
13	3601W125-19		Baffle Oven Front		Appelez-nous	-
14	2205W021-21		Bottom, Oven		Appelez-nous	-
15	4001F060-45		Housing, Bake Burner		Appelez-nous	-
16	WP7101P126-60		Screw   (Replaces: 7101P061-60)			Immediately	$ 6.85
17	3801F093-45		Bracket, Burner Box		Appelez-nous	-
17	7107P006-60		Rivet, Ov Bot Ret		Appelez-nous	-
18	WP7101P126-60		Screw   (Replaces: 7101P273-60)			Immediately	$ 6.85
18	3601W130-45		Baffle, Bake & Broil		Appelez-nous	-
19	4396923		Pan, Broil   (Replaces: 3401F004-19)			Immediately	$ 52.04
20	4396923		Insert, Broil Pan   (Replaces: 3413F002-19)			Immediately	$ 52.04

    View Diagram in Separate Window       Print Part List
