Diagram # Part Number Description Series Availability Ships Price Add to Cart
1 5303280334 Handle-utility Drawer Appelez-nous -
2 3131387 Fstnr-nylon Spacer (2) Appelez-nous -
3 3131134 Panel-drawer-almond Appelez-nous -
4 5303281651 Screw Handle (2) Appelez-nous -
5 3131975 Shield-panel Appelez-nous -
6 316011501 Drawer Body Appelez-nous -
7 3051163 Glide (2) In-Stock Immediately $ 19.41


    View Diagram in Separate Window     Print Icon   Print Part List

Diagram for 30-2761-23-03
