| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 72041-14-WW | Panel, F.f. Door (wht) |
|
- | |||||
| 1 | 67059-1 | Liner, Door |
|
- | |||||
| 2 | 28272-6 | Bumper, Door |
|
- | |||||
| 2 | 65031-1 | Shim, Upper Hinge |
|
- | |||||
| 3 | 67316-1 | Rail, P O Door |
|
- | |||||
| 3 | 66799-3 | Clip, Handle Screw |
|
- | |||||
| 3 | 65275-29 | Screw,handle Bottom (hex Head) |
|
- | |||||
| 4 | 400027-28 | Screw |
|
- | |||||
| 4 | 66651-4 | Trim, Door |
|
- | |||||
| 5 | 67385-1 | Shim, Handle |
|
- | |||||
| 5 | 67144-1 | Grommet, Pick-off |
|
- | |||||
| 5 | 67151-1 | Handle, Door |
|
- | |||||
| 6 | 65275-44 | Screw |
|
- | |||||
| 6 | 67032-2 | Retainer, Door Seal |
|
- | |||||
| 6 | 67882-3 | Insert Handle |
|
- | |||||
| 7 | 67805-10 | Trim Ext Upper |
|
- | |||||
| 7 | 67032-1 | Retainer, Door Seal |
|
- | |||||
| 8 | 67805-10 | Trim Ext Upper |
|
- | |||||
| 8 | 67745-6 | Gasket, F.f. Door |
|
- | |||||
| 9 | 65275-5 | Screw |
|
- | |||||
| 9 | 67156-1 | Bracket, Handle Upper |
|
- | |||||
| 10 | 67041-6 | Door, Dairy |
|
- | |||||
| 10 | 67156-1 | Bracket, Handle Upper |
|
- | |||||
| 11 | 67299-6 | Shim, Trim Lock |
|
- | |||||
| 11 | 67216-1 | Tray, Butter |
|
- | |||||
| 12 | 67299-7 | Shim, Trim Lock |
|
- | |||||
| 12 | 67090-2 | Shelf, Pick Off Ref |
|
- | |||||
| 13 | 67215-3 | Tray, Egg |
|
- | |||||
| 13 | 414004-1 | Screw |
|
- | |||||
| 14 | 67380-3 | Endcap, Handle |
|
- | |||||
| 14 | 67027-3 | Organizer |
|
- | |||||
| 15 | 67084-2 | Front, Pick Off Ref |
|
- | |||||
| 15 | WP3-24838-048 | Screw (Replaces: 9986-87) |
|
$ 7.00 | |||||
| 16 | 59920-8 | Rivet, P.o. Hook |
|
- | |||||
| 16 | 67229-4 | Cover, Upper Hinge(wht.) |
|
- | |||||
| 17 | 67043-2 | Hook,p.o. Shelf (left) |
|
- | |||||
| 17 | 67043-5 | Hook,p.o.shelf (right) (Replaces: 67043-1) |
|
Immediately | $ 32.93 | ||||
| 17 | 403060-1 | Screw, Hinge Cover |
|
- | |||||
| 18 | 67456-4 | Hinge, Top |
|
- | |||||
| 19 | WP52185-1 | Washer (Replaces: 52185-1) |
|
Immediately | $ 9.47 | ||||
| 20 | 54485-1 | Closer, Door |
|
- | |||||
| 21 | 52613-1 | Insulation, Closer |
|
- | |||||
| 22 | 52614-1 | Bracket, Closer |
|
- | |||||
| 23 | 69022-2 | Stop, Door |
|
- | |||||
| 24 | 65275-48 | Screw |
|
- | |||||
| 24 | 67386-1 | Clip, Handle |
|
- | |||||
| 25 | 65275-31 | Screw, Bracket To Handle |
|
- | |||||
| 26 | 67483-3 | Washer, Lower Hinge (Replaces: 67483-2) |
|
Immediately | $ 45.86 | ||||
| 27 | 68977-1 | Pin, Hinge |
|
- | |||||
| 28 | 68978-4 | Cover, Lower Hinge (wht) |
|
- | |||||
| 29 | 68975-6 | Hinge, Lower |
|
- | |||||
| 30 | 65275-51 | Screw, Lower Hinge |
|
- | |||||
| 31 | 69031-2 | Shim |
|
- | |||||
| 31 | 67874-1 | Tapping Plate, Lower Hinge |
|
- | |||||
| 31 | 65275-10 | Screw, Tapping Plate |
|
- |
