13 - Microwave Control Panel


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	4164483		Frame, Control Panel		Appelez-nous	-
2	4164484		Filter, Display		Appelez-nous	-
3	4164602		Unit, Control		Appelez-nous	-
3	4164603		Screws, Control Unit Mounting (3)		Appelez-nous	-
4	4164485		Plate, Control Panel Back		Appelez-nous	-
4	4164551		Screws, Control Panel Mounting (3)		Appelez-nous	-
4	4164552		Screw, Panel Frame Mounting		Appelez-nous	-
5	4164604		Relay Unit		Appelez-nous	-
5	4164550		Screws, Relay Unit Mounting		Appelez-nous	-
