10 - Drain Valve Assembly


11 - Soap Injection & Accessories


12 - Water Valve Assembly


13 - Water Valve Assembly (two Waters)


14 - Control Panel


15 - Main Control


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
001	23001244		Valve, Drain (240v-50/60hz)	10			$ 2,768.25
002	WP616099		Clamp, Hose (32-50)   (Replaces: 23001261)	10		Immediately	$ 7.03
003	23002012		Holder	10	Appelez-nous	-
004	23002013		Support, Outlet Valve	10	Appelez-nous	-
005	23002015		Elbow (90 Degree)	10	Appelez-nous	-
006	23001253		Tee, Drain	10	Appelez-nous	-
007	WP696392		Clamp, Hose (70-90)   (Replaces: 23001258)	10			$ 7.31
008	23001305		Bolt M8x25	10	Appelez-nous	-
009	23001266		Nut M8	10	Appelez-nous	-
010	23002137		Washer (8)	10	Appelez-nous	-
011	23001263		Washer (8.4)	10	Appelez-nous	-
012	23001662		Bolt (m10x30)	10	Appelez-nous	-
013	23002138		Washer (10)	10	Appelez-nous	-
014	NLA		Washer (10.5)	10	Appelez-nous	-
015	23001760		Hose, Overflow	10	Appelez-nous	-
016	23002018		Elbow	10	Appelez-nous	-
017	23001260		Bushing, Air Dome Hose	10	Appelez-nous	-
018	23001252		Hose, Water Level Switch	10	Appelez-nous	-
019	WP596669		Clamp, Corbin (a5.5)   (Replaces: 23001257)	10		Immediately	$ 7.56
020	WP616099		Clamp, Hose (20-32)   (Replaces: 23001262)	10		Immediately	$ 7.03
021	23001736		Nut (m14x1.5)	10	Appelez-nous	-
022	23002019		Seal (i)	10	Appelez-nous	-
023	23002139		Hose, Connection	10	Appelez-nous	-
024	23002140		Washer, Blind	10	Appelez-nous	-
