SELECT A DIAGRAM

01 - Blower Motor (cooling Fan Lower)


02 - Blower Motor (cooling Fan Upper)


03 - Body


04 - Body (lower)


05 - Body (lower)


06 - Body (upper)


07 - Control Panel (lower)


08 - Control Panel (upper)


09 - Door (lower)


10 - Door (upper)


11 - Internal Controls (lower)


12 - Internal Controls (upper)


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	04021191		Blower Assembly	1	Appelez-nous	-
2	Y04020842		Duct Assembly, Magnetron	1	Appelez-nous	-
3	Y02170111		Support, Duct Magnetron	1	Appelez-nous	-
4	03010138		Screw	1	Appelez-nous	-
5	02310109		Tape, Foam	1	Appelez-nous	-
6	02310070		Tape, Foam	1	Appelez-nous	-
7	02310071		Tape, Foam	1	Appelez-nous	-

    View Diagram in Separate Window       Print Part List
