| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | 5300809369 | Push Buttons |
|
- | |||||
| 2 | 5300809783 | Knob - Timer |
|
- | |||||
| 3 | 5300809036 | Lens |
|
$ 20.90 | |||||
| 4 | 5300805324 | Screw (2) |
|
- | |||||
| 5 | 5300809576 | Panel - Control |
|
- | |||||
| 6 | 5303210210 | Light Assy-delay |
|
- | |||||
| 7 | 5300807103 | Screw (2) |
|
- | |||||
| 8 | 240396801 | Clamp (Replaces: 5300808442) |
|
$ 19.13 | |||||
| 9 | 5300809175 | Screw 8b X 7/16`` |
|
- | |||||
| 10 | 5300808483 | Terminal Board |
|
- | |||||
| 11 | 3018037 | Terminal |
|
- | |||||
| 12 | 5300809883 | Block - 18 Pin |
|
- | |||||
| 13 | 5300809662 | Timer |
|
- | |||||
| 14 | 83350-2 | Nut (2) |
|
- | |||||
| 15 | 5300809790 | Switch - Selector |
|
- | |||||
| 16 | 5300809334 | Bracket - Switch |
|
- | |||||
| 17 | 5300809791 | Overlay - Panel |
|
- | |||||
| 18 | 5300809317 | Light Assy-pilot |
|
- |
