| Diagram # | Part Number | Description | Series | Availability | Ships | Price | Add to Cart | ||
|---|---|---|---|---|---|---|---|---|---|
| 001 | 301548 | Clamp, Ground (w/screw) | 00 |
|
- | ||||
| 002 | 301552 | Regulating Thermostat | 00 |
|
- | ||||
| 003 | NLA | No.4 Wire W/receptacles Gas | 00 |
|
- | ||||
| 004 | Y302278 | Motor | 00 |
|
- | ||||
| 005 | Y302455 | Switch | 00 |
|
- | ||||
| 006 | 302521 | Power Cord | 00 |
|
- | ||||
| 007 | NLA | Pilot Light | 00 |
|
- | ||||
| 008 | NLA | Door Switch Harness | 00 |
|
- | ||||
| 009 | NLA | Wire Harness | 00 |
|
- | ||||
| 010 | NLA | Main Wire Harness | 00 |
|
- | ||||
| 011 | WP694674 | Regulating Thermostat (Replaces: 303035) | 00 |
|
Immediately | $ 45.46 | |||
| 012 | NLA | Gas Valve Wires With Plug | 00 |
|
- | ||||
| 013 | Y303204 | Start Switch With Nuts | 00 |
|
- | ||||
| 014 | Y303224 | Selector Switch | 00 |
|
- | ||||
| 015 | Y303225 | Thermostat, Permanent Press | 00 |
|
$ 46.70 | ||||
| 016 | NLA | Wire Harness For Door Switc | 00 |
|
- | ||||
| 017 | NLA | Main Wire Harness | 00 |
|
- | ||||
| 018 | NLA | Main Wire Harness | 00 |
|
- | ||||
| 019 | NLA | Door Switch Harness | 00 |
|
- | ||||
| 020 | NLA | Door Switch Harness | 00 |
|
- | ||||
| 021 | NLA | Relay Harness | 00 |
|
- | ||||
| 022 | NLA | Main Wire Harness | 00 |
|
- | ||||
| 023 | NLA | Wire Harness, Main | 00 |
|
- | ||||
| 024 | Y303318 | Switch Assembly With Hex Nu | 00 |
|
- | ||||
| 025 | Y310376 | Clip, Wire Harness | 00 |
|
- | ||||
| 026 | W10850756 | Ground Lug (Replaces: Y311916) | 00 |
|
$ 6.98 | ||||
| 027 | W11164114 | Screw, No.10-24 X 3/4 Inch-----o (Replaces: Y312209) | 00 |
|
$ 3.76 | ||||
| 028 | Y312702 | Knurled Nut | 00 |
|
$ 18.18 | ||||
| 029 | Y312706 | Hex Nut On Switch | 00 |
|
- | ||||
| 030 | WPW10139799 | Lock Washer (Replaces: 312751) | 00 |
|
$ 8.32 | ||||
| 031 | Y201808 | Converter | 00 |
|
- | ||||
| 032 | 204051 | Knob | 00 |
|
Immediately | $ 164.03 | |||
| 033 | WP248562 | Wire Connector (Replaces: 211737) | 00 |
|
$ 6.95 | ||||
| 034 | 211881 | Grommet, Cord | 00 |
|
- | ||||
| 035 | WP488234 | Screw, No.8-32 X 1/4 Inch (Replaces: 212519) | 00 |
|
$ 6.07 | ||||
| 036 | 213099 | Lens For Control Panel | 00 |
|
- | ||||
| 037 | NLA | Harness Retainer | 00 |
|
- | ||||
| 038 | NLA | Screw, No.4-40 X 1/4 | 00 |
|
- |
