Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
1	2189685		Refrigerator Door (includes No.7) (almond)		Appelez-nous	-
1	2189684		Refrigerator Door (includes No.7) (white)		Appelez-nous	-
2	2171283		Load, Lock (4)		Appelez-nous	-
3	2171078		Door, Compartment		Appelez-nous	-
4	2193409		Beverage Holder				$ 48.13
5	2165792		Tray, Butter		Appelez-nous	-
6	2173825		Insert, Handle (white)		Appelez-nous	-
6	2173828		Insert, Handle (almond)		Appelez-nous	-
7	2159075		Door, Gasket Magnetic (service)			Immediately	$ 285.43
8	2173826		End Cap, Handle		Appelez-nous	-
9	489075		Screw		Appelez-nous	-
10	2192774		Retainer, Insert		Appelez-nous	-
11	WP489463		Screw   (Replaces: 489463)				$ 7.04
13	2159124		Gasket		Appelez-nous	-
14	WP489483		Screw   (Replaces: 489420)				$ 9.78
15	2155332		Bracket, Door Stop		Appelez-nous	-
16	4318417		Black Grille Kit		Appelez-nous	-
16	4210348		Black Acrylic Panel Kit		Appelez-nous	-
16	4211148		White Acrylic Panel Kit		Appelez-nous	-
16	4211147		Almond Acrylic Panel Kit		Appelez-nous	-
16	4318339		Handle Inserts (black)		Appelez-nous	-
16	4318340		Woodgrain Handle Inserts		Appelez-nous	-
16	2171063		Shelf Bin (4)		Appelez-nous	-
16	4318336		Trim Kit		Appelez-nous	-
