SELECT A DIAGRAM

01 - Frame And Cover Assembly


02 - Side Panels


03 - Outer Shell Assembly


04 - Inner Basket


05 - Door


06 - Door Lock Assembly


07 - Bearing Assembly


08 - Motor And Pulley


09 - Soap Box Assembly


10 - Control Panel


11 - Main Control


12 - Soap Injection & Accessories


13 - Water Valve Assembly


14 - Drain Valve Assembly


Diagram #	Part Number		Description	Series	Availability	Ships	Price	Add to Cart
001	23001244		Valve, Drain (240v-50/60hz)	10			$ 2,768.25
002	23002015		Elbow (90 Degree)	10	Appelez-nous	-
003	23001760		Hose, Overflow	10	Appelez-nous	-
004	23001253		Drain Tee	10	Appelez-nous	-
005	23002316		Holder	10	Appelez-nous	-
006	23002647		Screw (m8x25)	10	Appelez-nous	-
007	NLA		Nut M8	10	Appelez-nous	-
008	23001761		Hose, Connection (76x84)	10	Appelez-nous	-
009	WP696392		Clamp, Hose (70-90)   (Replaces: 23001258)	10			$ 7.31
010	WP616099		Clamp, Hose (32-50)   (Replaces: 23001261)	10		Immediately	$ 7.03
011	WP616099		Clamp, Hose (20-32)   (Replaces: 23001262)	10		Immediately	$ 7.03
012	WP596669		Clamp, Corbin (a5.5)   (Replaces: 23001257)	10		Immediately	$ 7.56
013	23003035		Elbow   (Replaces: 23001762)	10	Appelez-nous	-
014	23001260		Bushing, Air Dome Hose	10	Appelez-nous	-
015	23001252		Hose, Water Level Switch	10	Appelez-nous	-
016	23002439		Washer, Spring Lock (8)	10	Appelez-nous	-
017	23003769		Washer M8	10	Appelez-nous	-
018	23002015		Elbow (90 Degree)	10	Appelez-nous	-

    View Diagram in Separate Window       Print Part List
